Code	S749
Model	HPK-45
Capacity	50 x 50 x 5mm Angle Capacity
Weight (kg)	450
Weight (m³)	1.050
Weight (Freight)	450
Dimensions (cm)	70 x 100 x 150

SAHINLER

415V / (NO PLUG)

1 Year Warranty

TURKIYE

Product Brochure Instructions Manual [2 MB] Parts List [169 KB]Section Rolling Machine Risk Assessment

Section & Pipe Rolling Machine HPK-45 50 x 50 x 5mm Angle Capacity

Features

Hydraulic top roller adjustment with DRO display
Rolls are hardened & made from high quality steel
Drive shafts are hardened and ground with double taper roller bearing support
Machine can be set up in horizontal or vertical working position
Roving foot pedal control with emergency stop
Geared direct drive via motor & gearbox
Standard rolls and guide rolls are included
Two rollers are powered
Steel fabricated frame
European quality
Optional lateral side guide roll supports for rolling angle iron available

Includes

Steel fabricated frame
Two rollers are powered
Manual top roller adjustment

Optional Accessories

Please Note:
If rolling angle iron leg in it should be used with lateral side roller guide supports (S7455)
Angle iron machine roll dies - 3 piece set - (S741H)

Pipe & Tube Rolls also available In recommended accessories

Videos

Specifications

Compare 9 Products
ORDER CODE
MODEL
Powered Driven RollsQty
Bending RollsType
Top Roll Shaft Diameter (Ø)mm
Lower Roll Shaft Diameter (Ø)mm
Top Roll Diameter (Ø)mm
Lower Roll Diameter (Ø)mm
Flat Bar Edge Capacity - MS (size / Ø)mm
Flat Bar Capacity - MS (size / Ø)mm
Square Bar Solid Capacity - MS (size / Ø)mm
Rectangle Tube Capacity - MS (size / Ø)mm
Square Tube Capacity - MS (size / Ø)mm
Round Bar Solid Capacity - MS (size / Ø)mm
Round Tube Capacity - MS (size / Ø)mm
Round Pipe Capacity - MS (size / Ø)inch / mm
Angle Capacity - MS (size / Ø)mm
Motor PowerkW / hp
Voltage / AmperageV / amp
Dimensions (L x W x H)mm
Note: Requires Additional ToolingNo / Yes*
Nett Weightkg

S749
HPK-45
2
Manual Top
50
50
155
155
60 x 10 / 500
100 x 15 / 450
35 x 35 / 900
50 x 40 x 3 / 1200*
50 x 50 x 3 / 1700*
Ø35 / 600*
Ø70 x 2 / 1000*
Ø2" x 2.9mm / 1000mm*
50 x 50 x 5 / 1000 mm*
1.5 / 2
415
90 x 1360 x 1450
Yes* (S7455 for angle capacity)
400

S7401
HK-50A
2
Hydraulic Top
50
50
155
~
60 x 10 / 500
100 x 15 / 450
35 x 35 / 900
50 x 40 x 3 / 1200*
50 x 50 x 3 / 1700*
Ø35 / 600*
Ø70 x 2 / 1000*
Ø2" x 2.9mm / 1000mm*
50 x 50 x 5 / 1000*
1.5 / 2
415
750 x 900 x 1550
Yes*
490

S750
HPK-50
3
Hydraulic Top
50
50
152
162
60 x 10 / 600
100 x 15 / 600
35 x 35 / 600
70 x 30 x 3 / 1500*
50 x 50 x 3 / 1600*
Ø35 / 600*
Ø70 x 2 / 1200*
Ø2" x 2.9mm / 1000mm*
50 x 50 x 6 / 600
1.1 / 1.5
415
810 x 950 x 1500
Yes*
500

S754
HPK-65
3
Hydraulic - Left & Right
~
~
180
~
60 x 10 / 500
80 x 20 / 500
32 x 32 / 400
50 x 25 x 3 / 450*
45 x 45 x 3 / 600*
Ø35 / 350*
Ø60 x 2 / 600*
Ø2" x 3.91mm / 400mm*
60 x 60 x 6 / 650
3 / 4
415
1200 x 850 x 1200
Yes*
1000

S680
RR-5G
2 x Manual
Manual Bottom Right
~
~
~
~
~
25 x 3 / 125
~
~
~
Ø5 / 125
~
~
~
~
~
360 x 190 x 180
No
6

S6805
RR-6
2 x Manual
Manual Bottom Right
~
~
~
~
~
40 x 6 /
~
~
~
Ø10
~
~
~
~
~
200 x 200 x 310 (without handle)
No
15.2

S681
RR-10
2 x Manual
Manual Top
~
~
98
~
30 x 10 / 500 - (20 x 5 / 190)
50 x 10 / 400 - (20 x 5 / 160)
20 x 20 / 500 - (10 x 10 / 160)
~
~
~
~
~
~
~
~
500 x 480 x 680
No
185

S682
RR-24
2
Manual Top
~
~
~
~
~
~
~
~
50 x 50 x 1.6 / 1000
~
Ø76 x 2 / 1520
~
~
1.1 / 1.5
240 / 10
740 x 630 x 1030
No
287

S745
PK-35F
2
Manual Top
50
50
155
155
60 x 10 / 500
100 x 15 / 450
35 x 35 / 900
50 x 40 x 3 / 1200*
50 x 50 x 3 / 1700*
Ø35 / 600*
Ø70 x 2 / 1000*
Ø2" x 2.9mm / 1000mm*
50 x 50 x 5 / 1000 mm*
1.5 / 2
240 / 10
750 x 1000 x 1400
Yes* (S7455 for angle capacity)
400

ORDER CODE	HPK-45
MODEL	2
Powered Driven RollsQty	Manual Top
Bending RollsType	50
Top Roll Shaft Diameter (Ø)mm	50
Lower Roll Shaft Diameter (Ø)mm	155
Top Roll Diameter (Ø)mm	155
Lower Roll Diameter (Ø)mm	60 x 10 / 500
Flat Bar Edge Capacity - MS (size / Ø)mm	100 x 15 / 450
Flat Bar Capacity - MS (size / Ø)mm	35 x 35 / 900
Square Bar Solid Capacity - MS (size / Ø)mm	50 x 40 x 3 / 1200*
Rectangle Tube Capacity - MS (size / Ø)mm	50 x 50 x 3 / 1700*
Square Tube Capacity - MS (size / Ø)mm	Ø35 / 600*
Round Bar Solid Capacity - MS (size / Ø)mm	Ø70 x 2 / 1000*
Round Tube Capacity - MS (size / Ø)mm	Ø2" x 2.9mm / 1000mm*
Round Pipe Capacity - MS (size / Ø)inch / mm	50 x 50 x 5 / 1000 mm*
Angle Capacity - MS (size / Ø)mm	1.5 / 2
Motor PowerkW / hp	415
Voltage / AmperageV / amp	90 x 1360 x 1450
Dimensions (L x W x H)mm	Yes* (S7455 for angle capacity)
Note: Requires Additional ToolingNo / Yes*	400
Nett Weightkg

Recommended Accessories

S7455

Angle Iron Lateral Side Guide Roll Support Set
PK35F-GUIDE
Maximum Angle Iron Capacity - 50 x 50 x 6mm
Suits PK-35F, HPK-45, HPK-50 Section Rolling Machine

Code: S7455

S745H

Angle Iron Roll Dies
PK35F-ANGLE
40 x 40 x 3mm Angle Iron
Suits PK-35F Section Rolling Machine

Code: S745H

S741H

Angle Iron Roll Dies
PK35F-ANGLE
50 x 50 x 5mm Angle Iron
Suits PK-35F Section Rolling Machine

Code: S741H

S740D

25.4mm (OD) Tube Roll Dies
PK35F-25T
Set Of 3 Rolls, Suits 50mm Shaft
Suits Model PK-35F & HK-50A

Code: S740D

S740E

31.8mm (OD) Tube Roll Dies
PK35F-32T
Set Of 3 Rolls, Suits 50mm Shaft
Suits Model PK-35F & HK-50A

Code: S740E

S740A

38.1mm (OD) Tube Roll Dies
PK35F-38T
Set Of 3 Rolls, Suits 50mm Shaft
Suits Model PK-35F & HK-50A

Code: S740A

S740B

50.8mm (OD) Tube Roll Dies
PK35F-51T
Set Of 3 Rolls, Suits 50mm Shaft
Suits Model PK-35F & HK-50A

Code: S740B

S741B

1" Pipe (NB) Roll Dies
PK35F-25P
Set Of 3 Rolls, Suits 50mm Shaft
Suits Model PK-35F & HK-50A

Code: S741B

S741C

1-1/4" Pipe (NB) Roll Dies
PK35F-32P
Set Of 3 Rolls, Suits 50mm Shaft
Suits Model PK-35F & HK-50A

Code: S741C

S741D

1-1/2" Pipe (NB) Roll Dies
PK35F-38P
Set Of 3 Rolls, Suits 50mm Shaft
Suits Model PK-35F & HK-50A

Code: S741D

S741F

2" Pipe (NB) Rolls
PK35F-51T
Set Of 3 Rolls, Suits 50mm Shaft
Suits Model PK-35F & HK-50A

Code: S741F
