Machine Tool Accessories > Drilling Accessories > Drill - Jobber Sets
D126 HSS Jobber Drill Set 170 Pieces
HSS Jobber Drill Set

Toolmaster
Code:D126
Model:170 Pieces
Capacity:∅1 - ∅10mm
Weight (Nett):4.84 Kg
Weight (Cubic):0.004 m3
Weight (Freight):4.84 Kg
Dimensions:36 x 24.5 x 4.5
In Stock:Yes

HSS Jobber Drill Set

Description
HSS DRILL SET - 170 PIECE:Suitable for Industry.

Features
- HSS precision ground flutes
- 170 pieces
- 1-10mm
- 10 drills each size up to 8mm then 5 per size

Array
(
    [0] => D120
    [1] => D121
    [4] => D123
    [5] => D125
    [6] => D126
    [2] => D127
    [3] => D128
)

All Sorts: Array
(
    [0] => D120
    [1] => D121
    [2] => D123
    [3] => D125
    [4] => D126
    [5] => D127
    [6] => D128
)

All Codes +  All Sorts: Array
(
    [D120] => D120
    [D121] => D121
    [D123] => D123
    [D125] => D125
    [D126] => D126
    [D127] => D127
    [D128] => D128
)

Current: 3
Max: 5
Back: -1
Next: 1
First: D121
Second: D126
Third: D127
Fourth: D128
CODEFLUTESRANGENO. PIECESSTEPSWEIGHT (NETT)
D120Twist1-13mm250.5mm1.5kg
D121Twist1/16-1/2"291/64"1.56kg
D126 Precision Ground1-10mm1700.5mm4.84Kg
D127 Precision Ground1-13mm250.5mm1.5kg
D128 Precision Ground1/16-1/2"291/64"1.56kg
